Specifications
| Table Size: | 20.6” x 43.3” (522 x 1,100mm) |
| Travel (X, Y, Z): |
40” x 20” x 20” (1,016 x 510 x 510mm) |
| Spindle Taper: | NST No. 50 |
| Spindle Speed: | 20~10,000rpm – Gear Drive, 4-Step |
| Tool Storage Capacity: | 40 Pcs. (60 Opt.) |
| Tool Change Time (T-T/C-C): | 2.5 Sec. /8.0 Sec. |
| Rapid Feed (X, Y x Z): | 1,969ipm (50m/min) x 1,417ipm (36m/min) |
| Power Requirement: | 35KVA |
Features
• Ideal for machining larger size parts and molds
• Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
• Rigid Meehanite cast iron construction with in-house induction hardened solid box ways
• Choice of #40 or #50 taper spindles for maximum machining flexibility
• Standard 40-Tool ATC with 60 tools as available options
• Flexibility with the ability to add 4th/5th axis in the field
• Available with a 2-APC, high efficiency, factory installed shuttle style pallet system as an Option
